Replacement Parts List
Note: Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
CF-W4GWCZZBM
REF.NO. and AREA
PART NO.
DESCRIPTION
Q'TY
Main Block Unit
E1
CR-2032/K5A
COIN BATTERY
1
E2
DFJK12U112BB
PAD FFC
1
E3
DFJK20T108BB
SW PCB FFC
1
E4
DFJK9000ZA
DRIVE FFC
1
E5
DFJS957ZA
LCD CABLE
1
E6
DFJS979ZA
LAN CABLE
1
E7
DFJS959ZB
MODEM
CABLE
1
E8
DFJS960ZA
MAIN SUB CABLE
1
E9
DFJS961ZB
DC-IN CABLE
1
E10
DFJS962ZA
SP CABLE
1
E11
DL3U11436MAB
PCB, MAIN
RTL
1
E12
DL3U21436MAB
PCB, USB
RTL
1
E13
DL3UP1492KAA
PCB, SW
RTL
1
E14
N1ZYYY000002
ANTENNA PCB-L ASSY
1
E16
N1ZYYY000001
ANTENNA PCB-R ASSY
1
E18
N5HZC0000014
WIRELESS LAN MODULE
1
E19
UJDA769PD1-A
CD-R/RW, DVD-ROM DRIVE
1
E20
DL3UP1443AAA
FPC, HDD
1
E21
N3CABRD00011
HDD
1
E22
K1YYZZ000060
CONNECTOR
1
E23
L0AA01A00018
SPEAKER
1
E24
L5EDD3Q00023
LCD
1
E25
L9AAA5DB0010
SOLENOID
1
E26
N0GB1J000012
INVERTER
1
E27
N2AZZJ000038
KEY BOARD US
1
E28
N2EAYYY00001
TOUCH PAD
1
E29
N5HAZ0000012
MODEM
1
Accessories
A1
CF-AA1623AM6
AC ADAPTOR
1
A2
K2CG3DR00003
AC CABLE
1
A3
N4HULTA00009
LITHIUM ION BATTERY PACK
1
A4
DFQX5574ZA
MANUAL
1
A500
DFJS954ZA
MODEM CABLE
1
Packing Material
P1
DFPE0806ZA
HOLDER
1
P2
DFPE0812ZA
PAD W
1
P3
DFPE0819ZA
BATTERY SPACER
1
P5
DFPK1037ZA
ACCESSORIES BOX
1
P6
DFPK1180YA
PACKING CASE (EXPORT)
1
P7
DFPN0827ZA
CUSHION T
2
P8
DFPN0828ZA
CUSHION B
2
Mechanical Parts
K1
DFBC0314ZB-0
PAD BUTTON
1
K2
DFBD0180ZB-0
POWER KNOB
1
K3
DFBD0182ZA-0
LAN SW KNOB
1
K4
DFBD9006ZA-0
DISK EJECT KNOB ASSY
1
K5
DFBH3043ZA
HINGE-L USA
1
K6
DFBH3044ZA
HINGE-R USA
1
K7
DFBS0068ZC-0
LCD KNOB
1
K8
DFGB0089VB-0
PANASONIC LABEL
1
K9
DFGE0106ZB-0
PAD COVER
1
