Figure 60 - wayne burner - exploded view – Middleby Marshall PS200 series User Manual
Page 92
91
PS360WB70/EWB PS360WB70/EWB
PS200
PS220/224
PS310/314/360
PS360WB
Midco burner
Wayne burner
PS555
PS570S/PS570G
Description
42810-0125 42810-0126 42810-0120 42810-0127
36863
44664
43061
42810-0127 GAS CONVERSION KIT,
PROPANE TO NATURAL
22176-0010 22176-0016 22176-0004 22176-0014
31821
22176-0014
43059
22176-0014 MAIN ORIFICE, NATURAL
0.204/5.18mm
0.182/4.62mm
0.219/5.56mm
0.250/6.35mm
0.234/5.94mm
0.250/6.35mm
0.228/5.79mm
0.250/6.35mm
GAS
22174-0011
22174-0011
22174-0011
22174-0011
31818
22174-0011
22174-0011
22174-0011 PILOT ORIFICE, NATU-
0.028/0.71mm
0.028/0.71mm
0.028/0.71mm
0.028/0.71mm
0.032/0.81mm
0.028/0.71mm
0.028/0.71mm
0.028/0.71mm
RAL GAS
22174-0006* 22174-0006* 22174-0006 22174-0006 22174-0006* 22174-0006*
NONE*
22174-0006* BYPASS ORIFICE, NATU-
0.060/1.52mm/
0.060/1.52mm/
0.060/1.52mm/
0.060/1.52mm/
0.060/1.52mm/
0.060/1.52mm/
0.060/1.52mm/
RAL GAS
#53 drill
#53 drill
#53 drill
#53 drill
#53 drill
#53 drill
#53 drill
28092-0019 28092-0019 28092-0019 28092-0019 28092-0019 28092-0019 28092-0019 28092-0019 GAS VALVE SPRING KIT,
NATURAL GAS
42810-0122 42810-0123 42810-0119 42810-0124
36856
44665
43062
42810-0124 GAS CONVERSION KIT,
NATURAL TO PROPANE
22176-0007 22176-0017 22176-0003 22176-0015
31822
31980
43060
22176-0015 MAIN ORIFICE, PROPANE
0.1285/3.26mm
0.113/2.87mm
0.134/3.40mm
0.152/3.86mm
0.185/4.70mm
0.165/4.19mm
0.141/3.58mm
0.152/3.86mm
22174-0010 22174-0010 22174-0010 22174-0010
31819
22174-0010 22174-0010 22174-0010 PILOT ORIFICE, PROPANE
0.018/0.45mm
0.018/0.45mm
0.018/0.45mm
0.018/0.45mm
0.025/0.64mm
0.018/0.45mm
0.018/0.45mm
0.018/0.45mm
22174-0009* 22174-0009* 22174-0009 22174-0009 22174-0009* 22174-0009*
NONE*
22174-0009* BYPASS ORIFICE, PRO-
0.038/0.97mm/
0.038/0.97mm/
0.038/0.97mm/
0.038/0.97mm/
0.038/0.97mm/
0.038/0.97mm/
0.038/0.97mm/
PANE
#62 drill
#62 drill
#62 drill
#62 drill
#62 drill
#62 drill
#62 drill
28092-0018 28092-0018 28092-0018 28092-0018 28092-0019 28092-0018 28092-0018 28092-0018 GAS VALVE SPRING KIT,
(same as
PROPANE
natural gas)
*
NOTE
Bypass orifices are used ONLY on ovens equipped with an on-off gas regulation system (with a solenoid valve). These ovens include:
B. Part Number Reference - Gas Orifices and Gas Conversion Kits
Figure 60 - Wayne burner - exploded view
Pilot/ignitor
assembly
42810-0117
Pilot shield
27170-0204
Venturi
Wtih angled flame target:
27170-0223
With round flame target:
38127
Pilot orifice
See chart below
Main orifice
See chart below
Pitot tube assembly
(for use with 208/
240V motors)
42400-0640
Air shutter
42810-0087
Burner blower and motor assy
120V: 27170-0011
208/240V: 27170-0287
PS200-series
(through 3/02)
PS310
PS314
Ovens equipped with a PID modulated gas system (with a modulating valve) do not use a bypass orifice. These ovens include:
PS200-series
(4/02 or later)
SECTION 3 - SERVICING COMPONENTS
NOTE: Installations at higher altitudes have a lower ambient air pressure that disrupts the air-fuel mixture. To correct this
problem, smaller gas orifices are required. A general rule is a 4% reduction for each 1000 ft. (305m) above sea level. Refer
to the chart in the Appendices section (page 135) for a listing of orifice sizes showing this reduction.
PS360
PS360WB
PS360WB70
PS570S (through 8/00)
PS360EWB
PS555
PS570S
(9/00 or later)
PS570G
