3
1 - GENERAL INFORMATION
1-1. GENERAL IDENTIFICATION
1. THROTTLE TRIGGER
2. THROTTLE LOCK
3. ON/OFF IGNITION SWITCH
4. TOP ASSIST HANDLE
5. SPARK PLUG WIRE / SPARK PLUG
6. CHOKE LEVER
7. STARTER HANDLE
8. AIR CLEANER COVER
9. FUEL CAP
10. FUEL TANK
11. PRIMER BULB
12. HARNESS
13. CONTROL HANDLE
14. OPERATING TUBE
15. HOSE CLAMP
16. FLEX TUBE
17. THROTTLE LINKAGE
18. MUFFLER COVER
19. SPARK ARRESTER SCREEN
20. VENTED BACK PAD
21. INTERMEDIATE TUBE
22. 2-3/16” (56mm) NOZZLE
23. 1-9/16” (40mm) CONCENTRATOR NOZZLE
24. THROTTLE LINKAGE CLIPS
21
22
23
1
2
3
4
5
6
7
8
9
10
11 12
19
18
20
17
16
15
14
13
24
2
PLEASE READ
Dear Customer,
Thank you for purchasing a McCulloch product. With proper operation and maintenance, it will provide you with years of serv-
ice.
In order to make the best use of your investment, be CERTAIN to familiarize yourself with the contents of the ENTIRE user
manual before attempting to operate and maintain your unit.
Be sure to carefully follow the step-by-step instructions in this manual to start, operate and maintain your new product.
In the manual there will be the following call-outs: NOTE:, WARNING / CAUTION and WARRANTY.
A NOTE: is used to convey additional information, to highlight a particular explanation, or to expand a description.
A WARNING or CAUTION identifies a procedure which, if not undertaken or if improperly done, can result in serious person-
al injury and/or damage to the unit.
The (WARRANTY SYMBOL) serves notice that unless instructions or procedures are followed, any damage caused will
void the warranty and repairs will be at owner’s expense.
Pay particular attention to the safety precautions. They are written for your protection and contain important information you
must know to safely operate your blower.
FOR WARRANTY OR SERVICE CONTACT THE NEAREST AUTHORIZED SERVICE CENTER - LOCATE YOUR NEAREST
SERVICE CENTER BY CALLING THE TOLL FREE NUMBER IN THIS MANUAL.
INTRODUCTION
