59
1 461320 Lever, Parking Brake
2 482058 Grip, Parking Brake Lever
3 48544 Rod End, 3/8-24 LH
4 04020-17 Nut, 3/8-24 LH Thread
5 04004-39 Rod, 3/8-24 x 9.5"
6 04020-14 Nut, 3/8-24 RH Thread
7 48343-04 Clevis, 3/8-24
8 481990 Spring
9 04001-162 Bolt, Hex Head 3/8-24 x 8.25"
10 04020-14 Nut, 3/8-24
11 451260 Weldment, Brake Rod
12 48807 Spring
13 04041-07 Flatwasher, 3/8"
14 451224 Weldment, Brake
15 461469 Weldment, Brake Linkage
16 461470 Weldment, Brake Linkage
17 481601 Band, Brake
18 48114-05 Fitting, Grease
19 48589 Drum, Brake
20 481529 Motor, Hydraulic Wheel
21 461438 Hub, Wheel
22 04008-01 Stud, Wheel Mounting 1/2-20
23 48680 Nut, Castle 1.0-20 UNF
24 04061-06 Pin, Cotter 9/16" x 1.5"
25 04028-01 Nut, Lug 1/2-20
26 04021-10 Nut, Elastic Stop 5/16-18
27 482185 Wheel Assy 23 x 8.50-12 (42" Only)
481833 Tire, 23 x 8.50-12 (42" Only)
482186 Rim W/Valve Stem (42" Only)
482044 Wheel Assy 23 x 9.50-12 (48" & 52")
481659 Rim W/Valve Stem (48" & 52")
482194 Tire, 23 x 9.50-12 (48" & 52")
28 04063-25 Key, Woodruff 5/16 x 1"
29 04069-01 Pin, Rue Cotter 3/8" Diameter
30 04064-03 Pin, Clevis 3/8" Diameter x 2"
31 04021-19 Locknut, Hex 1/2-13 Center Lock
32 451179 Weldment, Deck Stop
33 451295 Weldment, Brake Shaft
34 04001-08 Bolt, Hex Head 5/16-18 x .75"
35 04021-10 Nut, Elastic Stop 5/16-18
36 482061 Bushing, Self-Aligning
37 04064-02 Pin, Clevis 3/8 x 1.06"
38 04021-09 Nut, Elastic Stop 3/8-16
39 04001-20 Bolt, Hex Head 3/8-16 x 1.5"
40 04061-02 Pin, Cotter 3/32 x .75"
41 04001-09 Bolt, Hex Head 5/16-18 x 1"
42 04019-03 Nut, Serrated Flange 5/16-18
43 04021-04 Nut, Elastic Stop 5/16-18
44 04050-12 E-Clip, .875"
45 04063-20 Key, 1/4 x 1/4 x 1"
46 451073 Brake Linkage Weldment, LH
47 451074 Brake Linkage Weldment, RH
-NOTE-
Ref. Part
No.
No. Description
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
PARKING BRAKE MECHANISM
purchased locally are a grade 5 unless otherwise noted.
