43
Ref. Part.
No. Number Description 42 48 52
1 482078 Cover, Spring x x x
2 04001-52 Bolt, Hex Head 1/2-13 x 2.5" x x x
3 04019-06 Nut, 1/2-13 Serrated Flange x x x
4 481993 Spring, Cutter Deck LIft x x x
5 04021-09 Nut, 3/8-16 Elastic Stop x x x
6 04001-19 Bolt, Hex Head 3/8-16 x 1" x x x
7 423234 Footplate x
422775 Footplate x x
8 481284 Bumper, Rubber x x x
9 48114-04 Fitting, Grease x x x
10 451386 Frame, Cutter Deck Mounting x
451196 Frame, Cutter Deck Mounting x
451381 Frame, Cutter Deck Mounting x
11 04066-01 Pin, Quick x x x
12 48100-17 Bushing, 1" ID Oilite x x x
13 482028-01 Plug, 1/4-28 x x x
14 45325 Yoke, Caster x x x
15 04021-07 Nut, 1/2-13 Elastic Stop x x x
16 43511 Spacer x x x
17 04001-80 Bolt, Hex Head 1/2-13 x 6.5" x x x
18 481843 Wheel, Caster 11 x 4.0-5 (Incl. items #19 through #24) x x x
19 482192 Tire, 11 x 4.0-5 x x x
20 481770 Retainer x x x
21 481769 Roller Bearing .625 x 3.25" x x x
22 481844 Rim, 5.0 x 3.25" x x x
23 481846 Roller Bearing .625 x 1.0" x x x
24 48114-05 Fitting, Grease x x x
25 481245 Knob, Cutter Deck Release x x x
26 43543 Rod, Threaded x x x
27 481992 Spring x x x
28 04060-08 Pin, Roll 3/16 x 1.5" x x x
29 451199 Pin, Deck Frame Pivot x x x
30 04003-04 Bolt, Carriage 5/16-18 x 1" x x x
31 04021-10 Nut, 5/16-18 Elastic Stop x x x
32 04019-03 Nut, 5/16-18 Serrated Flange x x x
33 04040-10 Flatwasher, 5/8-.688 x 1.750 x .134 x x x
34 43530 Bushing x x x
35 04050-16 Snap-Ring x x x
CUTTER DECK SUPPORT COMPONENTS
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
