MB QUART SCR - Manual (Page 47)

45
1 481559 Cap, Grease
2 04021-20 Nut, Elastic Jam 1.0-14
3 481657 Bearing, 1.0 Diameter
4 481025 Seal, 2.00 OD x 1.625 ID
5 04021-13 Nut, Elastic Stop 5/8-11
6 482028-01 Plug, 1/4-28
7 451187 Yoke, Wheel
8 04001-41 Bolt, Hex Head 5/8-11 x 9.5"
9 43021 Spacer
10 482043 Wheel Assy, 16 x 6.5-8 (Inc. # 11 thru # 16)
11 482192 Tire, 16 x 6.5-8
12 481897 Seal, Wheel Bearing
13 481896 Cone, Bearing
14 481897 Cup, Bearing
15 481894 Rim Assy, (Includes Item # 12, 13, 14, & 16)
16 48114-06 Fitting, Grease
17 451186 Weldment, Rear Caster Support
18 461319 Weldment, Main Frame RH
19 451171 Weldment, Main Frame LH
20 451173 Weldment, Axle Support
21 451174 Weldment, Seat Support
22 451177 Plate, Front Crossmember
23 451178 Weldment, Seat Plate
24 482220 Seat Assy.
25 451179 Weldment, Deck Stop
26 48015 Battery, purchase locally
27 461473 Cover, Instrument Panel
28 422855 Rear, Instrument Panel
29 451415 Weldment, Gearbox Support
30 422976 Plate, Gearbox Upper
31 423311 Mount, Fuel Tank Rear
32 422936 Box, Battery
33 423031 Heatshield
34 423233 Cover, PTO Clutch
35 482204 Spring, Seat
36 04029-03 Knob
37 482074 Pad, Rubber Hopper Rest
38 48657 Pad, Rubber
39 422935 Bracket, Hydraulic Filter Mounting
40 423252 Bracket, Fuel Tank Front
41 422934 Catch, Cutter Deck
42 451288 Weldment, Engine Deck
43 451256 Weldment, Muffler Guard
44 423005 Bracket, Oil Cooler
45 422988 Rod, Hopper Prop
46 04001-19 Bolt, Hex Head 3/8-16 x 1"
47 04030-04 Lockwasher 3/8"
48 04019-04 Nut, Serrated Flange 3/8-16
49 04003-33 Bolt, Carriage 7/16-14 x 1"
50 04019-05 Nut, Serrated Flange 7/16-14
51 04001-20 Bolt, Hex Head 3/8-16 x 1.5"
52 04021-09 Nut, Elastic Stop 3/8-16
53 04041-07 Flatwasher, 3/8"
54 04001-07 Bolt, Hex Head 1/2-13 x 1.5"
55 04021-07 Nut, Elastic Stop 1/2-13
56 04040-07 Flatwasher 1/2"
57 04030-06 Lockwasher 1/2"
Ref. Part.
No. Number Description
58 04001-32 Bolt, Hex Head 3/8-16 x 1.25"
59 04001-63 Bolt, Hex Head 5/16-18 x 3.5"
60 04021-10 Nut, Elastic Stop 5/16"
61 04017-16 Bolt, Capscrew 5/16-18 x .75"
62 43512 Spacer
63 04003-01 Bolt, Carriage 1/4-20 x 6"
64 04029-01 Wing Nut, 1/4-20 x .75"
65 04021-09 Nut, Elastic Stop 3/8-16
66 43462 Pin
67 04060-01 Roll Pin, Spring 5/32 x .75"
68 04003-12 Bolt, Carriage 5/16-18 x .75"
69 04019-03 Nut, Serrated Flange 5/16-18
70 04021-10 Nut, Elastic Stop 5/16-18
71 04032-01 Washer
72 04001-09 Bolt, Hex Head 5/16-18 x 1"
73 481625-01 Knob, w/stud 3/8-16 x 1-1/4"
74 04110-03 U-Nut, 3/8-16
Ref. Part.
No. Number Description
SHEET METAL
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
