11. MPS-5310 Specification
Transducer Type (x2)
• 12” Acrylic polymer coated heavy paper cone
• Acrylic polymer coated foam surround
• 1 Inch voice coil length
• 2 Inch voice coil diameter
• Kapton (voice coil former bonded with high temperature epoxy)
• Voice coil is asymmetrically hung
• Under cut ventilated pole piece
• Bumped back plate
• 38 oz ceramic main magnet
• 26 oz bucking magnet with foam damper
Rated Power Output 350 Watts RMS
Peak Power Output (20 millisecond pulse) 600 Watts
Amplifier Distortion Less than .03% from 20Hz to 200Hz at
full output.
Differential Input Impedance
Balanced 61K Ohms
Unbalanced 15K Ohms
Amplifier Noise Relative To Full Output -90dB
Maximum Acoustic Output 113dB @ 1 Meter
(pass band 40Hz - 150Hz)
Response (Anechoic)
THX Position -3dB at 35Hz
+/-1dB pass band (40Hz to 150Hz)
-3dB at 200Hz
Anechoic Position -3dB at 20Hz
+/-1dB pass band (40Hz to 150Hz)
-3dB at 200Hz
Low Pass Filter
80Hz Filter 24dB per Octave 80Hz
Variable Filter 36dB per Octave - 50Hz to 125Hz
Dimensions (H x W x D) 23” x 15 1/4" x 19 5/8”
Weight 84 lbs
Replacement Fuse Values
110 Volt (US) External Fuse 6.0 Amp 3AG - 1/4" x 1 1/4" Slow-Blow
220 Volt (US) External Fuse 3.0 Amp 3AG - 1/4" x 1 1/4" Slow-Blow
220 Volt (IEC 127-2III) External Fuse T 3.15 A 5 x 20 mm Time-Lag
Internal Fuse (all versions) 7.0 Amp 3AG - 1/4" x 1 1/4" Fast-Blow
