2
SECTION 1
DESCRIPTION
PS528 SERIES OVEN SPECIFICATIONS
Conveyor Belt Width 18.00" (457mm)
Heating Zone Length 28.00" (711mm)
Baking Area Square Feet 3.5 sq. ft. (0.33 sq. m.)
Overall Dimension
Standard Single Oven w/Legs 50.00" (1270mm) L ×
40.75" (1035mm) W ×
21.72" (786mm) H ×
Overall Dimension
Double Oven 50.00" (1270mm) L ×
40.75" (1035mm) W ×
37.27" (947mm) H x
Overall Dimension
Triple Oven 50.00" (1270mm) L x
40.75" (1035mm) W ×
52.82" (1342mm) H ×
Weight of Single Oven 250 lb (93.3kg)
Shipping Weight 325 lb (121.3kg)
Shipping Cube 22.1 ft 3 (0.62 m 3 )
BTU's - Natural or Propane Gas 50,000 BTU/hr (53 MJ/hr)
Gas Input - Natural or Propane Gas 1/2" NPT (1/2" BS)
Maximum Operating Temperature 600°F (316°C)
Warm-up Time 20 min.
Belt Speed Limits 1-10 minutes
SERIES PS528 ELECTRICAL SPECIFICATIONS
Main Blower & Control Circuit Phase Frequency Amperage Poles Wires
Elements Voltage Voltage Draw
208-240V 208-240V 1 Ph 50/60 Hz 1.5 Amp 2 Pole 3 Wire
(2 hot, 1 grd)
GAS ORIFICE AND PRESSURE SPECIFICATIONS (PER OVEN CAVITY) - CE OVENS
Supply (Inlet) Pressure
IT,PT,ES,SE,
Main UK,CH,IT,AT, SE,CH,AT,DK, BE,IE,IT,PT, Orifice Rated
Gas Orifice DK,FI DE BE,FR FI,DE,NL ES,UK (Manifold) Heat
Type dia. I
2H
I
2E
I
2E+
I
3B/P
I
3+
Pressure Input
G20 2.3749 20 20 20 -- -- 11.21 22.36
mm mbar mbar mbar mbar kW-hr.
G25 2.3749 -- -- -- -- -- 16.19 22.36
mm mbar kW-hr.
G30 1.3970 -- -- -- 29 or 50 28-30, 37 26.2 22.59
mm mbar or 50 mbar mbar kW-hr.
GAS ORIFICE AND PRESSURE SPECIFICATIONS (PER OVEN CAVITY) - DOMESTIC AND STANDARD EXPORT OVENS
Orifice (Manifold)
Gas Type Main Orifice I.D. Supply (Inlet) Pressure Pressure
Natural #42 drill (.094")(2.38mm) 6-8” W.C. (14.9-19.9mbar) * (1.49-3 KPA) 3.5” W.C. (8.72mbar) (0.872 KPA)
Propane #48 drill (.076")(1.93mm) 6-8” W.C. (14.9-19.9mbar) * (1.49-3 KPA) 3.5” W.C. (8.72mbar) (0.872 KPA)
* The gas supply pressures and orifice sizes shown are for ovens installed in North America. The required gas supply pressures and orifice sizes
of ovens installed in other locations are dependent on the local gas type and on all applicable local codes.
NOTE
Wiring Diagrams are contained in Section 6 of this Manual
and are also located inside the oven at the
bottom of the Control Panel.
Additional electrical information is provided on the oven's serial plate.
This Manual Must Be Kept For Future Reference.
