AC CONNECTION
Insert the small end of the AC adapter into the
jack on the side of the unit. Insert the other end
(with the 2 blades) into a conveniently located
AC outlet having 120V AC, 60Hz. DO NOT insert
into the DC IN CHARGE jack.
AC ADAPTER SPECIFICATIONS: DC 9V Z
NOTES:
• To disconnect the AC adapter, remove it
from the DC IN jack on the side of the unit as
well as from the AC outlet.
• Use the enclosed AC adapter for this
product only.
BATTERY PACK INSERTION/REMOVAL
Follow the instructions below to insert or remove the Battery Pack.
7
POWER SOURCES
TO REMOVE: Slide the Battery Release
switch in the direction of arrow A, then slide
the Battery Pack in the direction of arrow B.
1
TO INSERT: Align tabs from the Battery Pack
into the holes in the unit, then slide the
Battery Pack in the direction of arrow A.
2
To DC 9V IN Jack
