English – Makita HM0860C User Manual
Page 5
5
ENGLISH
Explanation of general view
1
Switch lever
2
Adjusting dial
3
Power-ON indicator lamp
(green)
4
Service indicator lamp ( red )
5
Side grip
6
Side handle
7
Can be swung 360° on the
vertical and secured at any
desired position
8
Secures at eight different
positions back and forth
on the horizontal
9
Clamp nut
10
Loosen
11
Tighten
12
Bit
13
Chuck cover
14
Commutator
15
Insulating tip
16
Carbon brush
17
Screwdriver
18
Brush holder cover
19
Brush holder cap
20
Screw
21
Terminal
22
Crank cap
23
Hammer grease
SPECIFICATION
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Note: Specifications may differ from country to country.
Intended use
The tool is intended for chiselling work in concrete, brick,
stone and asphalt as well as for driving and compacting
with appropriate accessories.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated in accordance with European Standard
and can, therefore, also be used from sockets without
earth wire.
Safety hints
For your own safety, please refer to the enclosed safety
instructions.
ADDITIONAL SAFETY RULES
ENB009-1
1.
Hold tools by insulated gripping surfaces when
performing an operation where the cutting tool
may contact hidden wiring or its own cord. Con-
tact with a “live” wire will make exposed metal
parts of the tool “live” and shock the operator.
2.
Wear ear protectors when using the tool for
extended periods. Prolonged exposure to high
intensity noise can cause hearing loss.
3.
Wear a hard hat (safety helmet), safety glasses
and/or face shield. It is also highly recom-
mended that you wear a dust mask and thickly
padded gloves.
4.
Be sure the bit is secured in place before opera-
tion.
5.
Under normal operation, the tool is designed to
produce vibration. The screws can come loose
easily, causing a breakdown or accident. Check
tightness of screws carefully before operation.
6.
In cold weather or when the tool has not been
used for a long time, let the tool warm up for a
while by operating it under no load. This will
loosen up the lubrication. Without proper warm-
up, hammering operation is difficult.
7.
Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
8.
Hold the tool firmly with both hands.
9.
Keep hands away from moving parts.
10. Do not leave the tool running. Operate the tool
only when hand-held.
11. Do not point the tool at any one in the area when
operating. The bit could fly out and injure some-
one seriously.
12. Do not touch the bit or parts close to the bit
immediately after operation; they may be
extremely hot and could burn your skin.
SAVE THESE INSTRUCTIONS.
Model
HM0860C
Blows per minute (min
–1
)
1,100 – 2,650
Overall length
454 mm
Net weight
4.7 kg
Safety class
/II
