NPort 5400 Series User’s Manual Web Console Configuration
5-9
NPort’s Auto IP report.
1. Use NPort Administrator’s IP Address Report function.
2. Refer the Appendix E for the “Auto IP report protocol” to develop your own software.
Auto report to IP
Setting Factory Default Necessity
E.g., 192.168.1.1 or URL
(IP addresses of the form x.x.x.0 and
x.x.x.255 are invalid.) None Optional
Reports generated by the Auto report function will be automatically sent to this IP address.
Auto report to TCP port
Setting Factory Default Necessity
E.g., 4001 4002 Optional
Auto report period
Setting Factory Default Necessity
Time interval (in seconds) 10 Optional
Serial Settings
Click on Serial Settings, located under Main Menu, to display serial port settings for ports 1 and
2.
To modify serial settings for a particular port, click on either Port 1 or Port 2 under Serial
Settings.
