33
MODEL NUMBERS
HR652DJRT HR650DJRS HR650DJLS HR666DJRT HR6120DJRT
KEY PART HR682DJRT
NO. DESCRIPTION PART NUMBERS
1 Temperature-Pressure Relief Valve 66001700 66001700 66001682 66001700 66001700
2 Dip Tube 66001874 66001307 66001303 †† 66001309 66001309
3 Primary Anode 66001730 66001730 66001729 66001731 66001873
4 Drain Valve 66001246 66001246 66001647 66001246 66001246
5 Drain Valve Washer 66001021 66001021 66001021 66001021 66001021
(17/32”x 13/64”x 1/8” thick)*
6 Element Gasket (10 pack) 66001053 66001053 66001053 66001053 66001053
7 Lower Element SEE NOTE ON PAGE 32
8 Thermostat Bracket 66001054 66001054 66001054 66001054 66001054
9 2 Pole Thermostat 66001201 66001201 66001201 66001201 66001201
(Two Wire Lead Models)†
10 Terminal Cover (Lower) 66001268 66001268 66001268 66001268 66001268
11 Lower Thermostat w/Hi Limit 66001202 66001202 66001202 66001202 66001202
(Three Wire Lead Models)†
12 Terminal Cover (Lower Three Wire) 66001064 66001064 66001064 66001064 66001064
13 Lower Access Panel 66001703 66001703 66001703 66001703 66001703
14 Upper Access Panel 66001703 66001703 66001703 66001703 66001703
15 Terminal Cover (Upper) 66001064 66001064 66001064 66001064 66001064
16 Upper Thermostat w/Hi Limit 66001254 66001254 66001254 66001254 66001254
17 Thermostat Bracket 66001054 66001054 66001054 66001054 66001054
18 Upper Element SEE NOTE ON PAGE 32
19 Element Gasket (10 pack) 66001053 66001053 66001053 66001053 66001053
20 Nipple w/Heat Traps — 66001707 66001744 — —
20 Nipple w/o Heat Traps 66001734 — — ††† 66001736 66001737
21 Pipe Insulation 66001708 66001708 66001708 66001708 66001708
22 T&P Insulation — 66001709 66001709 — —
# Manual 66001869
Repair Parts List (cont’d)
MAYTAG ELECTRIC WATER HEATERS
MODEL NUMBERS
HR652DJRT 50 GALLON
HR650DJRS 50 GALLON
HR650DJLS 50 GALLON
HR666DJRT 66 GALLON
HR682DJRT 80 GALLON
HR6120DJRT 119 GALLON
*Also available at most hardware stores.
†Refer to Wiring Diagram Section for verification.
††66001309 for Model HR682
†††66001735 for Model HR682
#Not Illustrated
Now that you have purchased this water heater, should
a need ever exist for repair parts or service, simply call
Maytag Customer Service at 1-800-788-8899 for an
authorized servicer. Be sure to provide all pertinent
facts when you call or visit.
The model number of the water heater will be found on
the model rating plate located above the access panel.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE
THE FOLLOWING INFORMATION:
Model Number
Serial Number
Part Number (if available)
Part Description
Voltage and Element Wattage
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
