8 75D0004
MLDV Series Gas Fireplace
71” Minimum
Ceiling
12” Max.
Depth
14” Min.
From Opening
6” Min.
to Opening
FP1987
clearances
FP1988
Mantel clearances
116 "
9556QE"
14"
12"
10"
8"
Wall
Stud
Insulation
Board
FP1988
Top of Fire-
place Opening
CLEARANCES
CLEARANCES TO COMBUSTIBLES
MANTEL CLEARANCES
NOTE: The combustible area above the facing must not protrude more than 3/4" from the facing. If
it does, it is considered a mantel and must meet the mantel requirements listed in this manual.
Figure 4 -
Side Wall and Ceiling Clearances
Figure 5 -
Mantel clearances.
6"
5"
3"
256O"
456O"
45°
356O"
1"
156O"
FP1949
mantel clearances
Fireplace
Opening
Wall
Combustible
Material Area
Side Wall
Combustible
Mantel
Top View
Follow these instructions carefully to ensure safe installation. Failure
to follow instructions exactly can create a fire hazard.
The appliance cannot be installed on a carpet, tile or other combustible
material other than wood flooring. If installed on carpet or vinyl flooring,
the appliance shall be installed on a metal, wood or noncombustible
material panel extending full width and depth of the appliance.
Side View
W
ARNING
