4 parts of the washing machine, 5 detergent compartment – Maytag MAF 9801 User Manual
Page 7
7
Start/Stop
P3
P1
P2
P4
Menu
Enter
4 PARTS OF THE WASHING MACHINE
1. DETERGENT COMPARTMENT - PRE-WASH
2. DETERGENT COMPARTMENT - MAIN WASH
3. FABRIC CONDITIONER COMPARTMENT
5 DETERGENT COMPARTMENT
1. DETERGENT COMPARTMENT
2. MAIN POWER SWITCH
3. PROGRAMME PANEL
4. DATA PLATE
5. COVER - DRAIN PUMP
6. DRAIN PUMP (BEHIND THE COVER)
7. WASHER DOOR
8. OUTER DOOR
5
4
2
3
1
6
7
8
1
2
3
