LACP
If enable, the group is LACP static trunking group. If disable, the
group is local static trunking group. All ports support LACP dynamic
trunking group. If connecting to the device that also supports LACP,
the LACP dynamic trunking group will be created automatically. If
LACP enable, users can configure LACP Active/Passive status in
each ports
Work Ports
The max number of ports can be aggregated at the same time. If it
belongs to LACP static trunking group, the exceed ports is put to
standby and able to aggregate if work ports fail. If is belongs to local
static trunking group, the number must be the same as group ports.
Click to activate the setting.
5.7.2 Aggregator Information
When users are setting LACP aggregator, related information will be
displayed in this interface. This page is Actor and Partner trunking one group
with port 1 to port 1.
5.7.3 State Activity
A link having either two active LACP ports or one active port can perform
dynamic LACP trunking. A link has two passive LACP ports will not perform
dynamic LACP trunking because both ports are waiting for LACP protocol
packet from the opposite device. If users are active LACP’s actor, when
selecting trunking port, the active status will be created automatically.
