Assembling Adapter and I/O Base
870 USE 103 00 May 2001 21
Labeling the Assembled Module
Overview A front panel label is supplied with each I/O base. The user should fill out the label
and affix it to the front panel of the adapter.
What Goes on
the Label? The user should fill out the label to identify the field wiring connections and
application of the I/O base terminals.
Example of a
Label A fill-in label is illustrated in the diagram below. The numbered pointers in the
diagram refer to the descriptions in the table that follows.
The following table describes the numbered pointers above.
Where Does the
Label Go? The label should be affixed to the front panel of the adapter in such a way that the
cutout area above the I/O model number allows the pre-screened model number of
the adapter to show through.
No. Description
1 Fields for plant name, station name and network address
2 Cutout–the model number of the Adapter shows through
3 Model Number of the I/O base
4 Color code of the I/O base
5 Short description of the I/O base
6 Field for the symbol name of inputs
7 Area for the symbol name of outputs
6
7
5
3
4
2
1
