Introduction
870 USE 103 00 May 2001 15
Ports and Cabling
Overview This section provides information about ports and cabling for the Momentum
Modbus Plus Communication Adapters.
Ports Model 170 PNT 110 20 has one Modbus Plus port for connection to a network with
a single trunk cable.
Model 170 PNT 160 20 has two ports for connection to either a single-cable or dual-
cable network.
Cabling Network port connections are compatible with standard Modbus Plus drop cables.
Drop cables are available from Schneider Automation in three standard lengths:
2.4m (8ft), 3m (10ft), and 6m (20ft).
