Introduction
870 USE 103 00 May 2001
13
Example of Node
Address
Assignment
The figure below shows typical address assignments for a network with one
controller and four communication adapters.
Modbus Plus
Communication
Adapters
with
I/O Bases
Node 1
Node 4
Node 2
Node 5
Node 3
Programmable Controller
with Modbus Plus Port
(Assigned Node Address 1)
