5
Assembling the product
Assembling Assembly
Vacuum
Blower
·
„
В
‚
М
П
Note Make sure the correct end is fixed to
the blower adapter, (smooth end).
Nozzle
When using the brush nozzle Ò to get extra
suction place your finger over the hole. This
is only for vacuuming
H
Н
О
Т
·
·
·
К
Cleaning turbo nozzle (pets models only)
If the turbo nozzles rotating brush becomes
entangled with hair it may require taking apart
and cleaning
1
Unclip the top half of the nozzle by pulling
the upper casing out slightly and lifting
off.
E
Clear out any blockages /pet hair, remove
all components.and clean if necessary.
2 The main turbo wheel has a removable
collar, this must be re-assembled
correctly, other wise the nozzle will not go
back together.
3 To re-assemble nozzle, take the brush bar
with the toothed belt positioned over the
track on the bar (notice the rectangular
locators on either side of
the brush bar).
F
Slot the brush bar into the
relevent tracks on either
side of the lower casing.
Ensuring that the turbo wheel is correctly
placed, loop the toothed wheel through the
belt and lower the turbo wheel into the
grove, provided in the lower casing. The
internal assembly should be complete.
4 Ensuring that the brush bar, the turbo
wheel and the belt are correctly located
and positioned, take the top casing
and position the slots over the teeth at
the front of the lower casing and clip
back into position.
E
F
G
H
Í
After re-assembly fit turbo nozzle on unit and
ensure the brush bar is rotating correctly.
‚
