Chapter 1 – Product Description and Specifications
Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354B) 5
Types of Adapters Available
Product Adapter Description Region
MTS2SA-T Serial-to-Serial + IP (External Power) Global
MTS2SA-T-R Serial-to-Serial + IP (RS-232 Power) Global
Note: The MTS2SA-T-R (RS-232 Powered) Adapter requires power to be supplied into
Pin 6 of the female DB9.
Package Contents
• One MultiConnect Adapter
• One universal power supply with power cord included with the externally powered adapters
• One RS-232 cable included with the RS-232 Serial-to-Serial Adapter
• Two mounting brackets
• Four adhesive-backed rubber feet (table-top mounting)
• One Quick Start Guide
• One MultiConnect CD
Handling Precautions
All devices must be handled with certain precautions to avoid damage due to the accumulation of static charge.
Although input protection circuitry has been incorporated into the devices to minimize the effect of this static buildup,
proper precautions should be taken to avoid exposure to electrostatic discharge during handling and mounting.
