Parts and functions
Front
COAXIAL DIGITAL AUDIO OUT jack
RF IN (VHF/UHF) jack
AC power cord
Power Skip Play Stop Skip Volume Open/Close T.Rec Rec/Otr Power Rec/Otr Channel F.Fwd Play Stop/
Eject Rew (Mono) Phones L – Audio In – R Video In
Volume ▲/▼ buttons
Phones jack
Video In jack
Audio In (L/R) jacks
Rew (Rewind) button (VCR)
F.Fwd button (VCR)
Rec/Otr button (VCR)
Play button (VCR)
Stop/Eject button (VCR)
Stop button (DVD)
Play button (DVD)
Open/Close button (DVD)
Disc tray
Skip buttons (DVD)
Power button
Channel ▲/▼ buttons
Power indicator
Remote sensor
Rec/Otr indicator (VCR)
T.Rec indicator (VCR)
Cassette loading slot
Rear
