2 Protective shields

prevent scratches to the chimney
during installation.

2 hose clips

for securing the

exhaust ducting to the exhaust
connection.

1 reducing collar

for use with 5"

(125 mm) exhaust ducting.

1 non-return flap

Upper retaining

plate secures the

chimney extension.

Lower retaining plate

Locking plate

secures the

canopy.

8 screws 5 x 40 mm

for supporting the

motor assembly and canopy.

(S8 wall anchors included in packaging
are not for use in USA/CDN.)

6 Screws 3.9 x 7.5 mm

for securing the

chimney and chimney extension.

CAUTION:
During the installation process
please be careful of sharp edges
that can cause harm.

Installation accessories
