7
Selecting the action mode
When selecting an action mode, first set the change lever
and the shift lever to the position shown in the figure. Then
proceed as follows.
Rotation with hammering
For drilling in concrete, masonry, etc., depress the lock but-
ton and rotate the change lever so that the pointer points to
the
symbol. Use a tungsten-carbide tipped bit.
Rotation only
For drilling in wood, metal or plastic materials, depress the
lock button and rotate the change lever so that the pointer
points to the
symbol. Use a twist drill bit or wood bit.
Hammering only
For chipping, scaling or demolition operations, depress the
lock button and rotate the change lever so that the pointer
points to the
symbol. Use a bull point, cold chisel, scaling
chisel, etc.
1. Change lever
2. Shift lever
3. Lock button
4. “Rotation with hammering” symbol
1
3
4
2
003126
1. Pointer
2. “Rotation with hammering” symbol
1
2
003129
1. Pointer
2. “Rotation only” symbol
1
2
003132
1. Pointer
2. “Hammering only” symbol
1
2
003134
