Instrument cluster and indicators, Meters and gauges, Instrument cluster and indicators -20 – Mazda 2007 SPEED6 User Manual
Page 159: Meters and gauges -20
Black plate (158,1)
Meters and Gauges
When the ignition switch is in the ON position, the dashboard gauges illuminate.
Speedometer ...................................................................................................... page 5-21
Odometer, Trip Meter and Trip Meter Selector .................................................. page 5-21
Tachometer ........................................................................................................ page 5-22
Engine Coolant Temperature Gauge .................................................................. page 5-22
Fuel Gauge ........................................................................................................ page 5-23
5-20
Driving Your Mazda
Instrument Cluster and Indicators
Mazdaspeed6_8V77-EA-06F_Edition1 Page158
Tuesday, May 9 2006 10:44 AM
Form No.8V77-EA-06F
