341
Technical data
Engine
Model C 320 (203.064) 1
C 320 4MATIC (203.084) 1
C 320 Sport (203.064) 1
C 32 AMG (203.065) 1
Engine 112 112
Mode of operation 4-stroke engine, gasoline injection 4-stroke engine, gasoline injection
No. of cylinders 6 6
Bore 3.54 in (89.90 mm) 3.54 in (89.90 mm)
Stroke 3.31 in (84.00 mm) 3.31 in (84.00 mm)
Total piston displacement 195.2 cu in (3199 cm 3 ) 195.2 cu in (3199 cm 3 )
Compression ratio 10:1 9:1
Output acc. to SAE J 1349 215 hp/5 700 rpm
(160 kW/5700 rpm) 349 hp/6100 rpm
(260 kW/6100 rpm)
Maximum torque acc. to SAE J 1349 229 lb-ft/3000 - 4600 rpm
(310 Nm/3000 - 4600 rpm) 332 lb-ft/4 400 rpm
(450 Nm/4400 rpm)
Maximum engine speed 6000 rpm 6 200 rpm
Firing order 1-4-3-6-2-5 1-4-3-6-2-5
Poly-V-belt 2380 mm 2 908 mm
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment.
