14
CABLE
VHF
2-13
STD/HRC/IRC
14-36
(A) (W)
37-59
(AA) (WW)
60-85
(AAA) (ZZZ)
86-94
(86) (94)
95-99
(A-5) (A-1)
100-125
(100) (125)
01
(5A)
TV
VHF
2-13
UHF
14-69
TV operation
If a channel with no broadcast is
selected, the sound will automati-
cally be muted.
If a station being viewed stops
broadcasting, the TV will automati-
cally shut itself off after 15 minutes.
To turn on the TV/DVD, press
POWER.
Set the TV/CABLE menu
option to the appropriate
position. (See page 17.)
TV - VHF/UHF channels
CABLE - CABLE channels
VOLUME 32
CH 02
Adjust the volume level by
pressing VOL + or – . The
volume level will be indicated on
the screen by green bars. As the
volume level increases, so do
the number of bars. If the volume
decreases, the number of green
bars also decreases.
CABLE Mode Direct Channel Selection
When the TV/CABLE menu option is in the CABLE position, channels
can be selected as follows:
TO SELECT Cable TV CHANNELS:
1-9:
Press “0” twice, then 1-9 as needed. Example, to select
channel 2, press “002”.
10-12: Press “0”, then the remaining 2 digits. Example, to
select channel 12, press “012”.
13-99: Press the 2 digits in order. Example, to select channel
36, press “36”.
100-125: Press the 3 digits in order. Example, to select channel
120, press “120”.
NOTE FOR CHANNELS 1-12:
If only 1 or 2 buttons are pressed, the corresponding channel
will be selected in 2 seconds.
1
2
3
4 Press the Direct Channel selection
buttons to select the channel.
TV Mode Direct Channel Selection
When the TV/CABLE menu option
is in the TV position, all channels
can be instantly selected by using
two buttons. (for example, to select
channel 2, press “0”, then “2”. If
you press only “2”, channel
selection will be delayed for a few
seconds.) For channels 10 and
above, press the 2 digits in order.
NOTES:
•
•
