MTD 240 Series - Manual (Page 17)

17
9
Parts List
For a proper working
machine, use Fac-
tory Approved Parts.
V-BELTS are specially
designed to engage and
disengage safely. A
substitute (non-OEM)
V-Belt can be danger-
ous by not disengaging
completely.
To order
replacement parts, call
1-800-800-7310
or visit
www.mtdproducts.com
1 749-04282 Upper Handle
2 720-04072 Star Handle Knob
3 749-04281 Lower Handle
4 710-04398 Flange Screw 5/16-18 x 7.5
5 754-04123 Belt
6 756-04163 Idler Pulley
7 748-04125 Shoulder Spacer
8 686-04080 Idler Bracket
9 712-04065 Flange Lock Nut: 3/8-16
10 710-0654A TT Screw 3/8-16 x 1.00
11 786-04303 Frame
12 710-0514 HH Cap Screw 3/8-16 x 1.00
13 732-0418 Extension Spring
14 738-04139 Stud 33 x 1.5 x 3/8-16
15 756-04217 Flywheel Pulley
16 710-0591 HH Cap Screw 3/8-24 x 1.00
17 710-0520 HH Cap Screw 3/8-16 x 1.50
18 786-04256 Tine Shield 61 cm
19 711-0415 Clevis Pin
20 642-0005 Outer Tine Assembly LH
21 642-0003 Inner Tine Assembly LH
22 714-0149B Internal Cotter Pin
23 710-0809 TT Screw 1/4-20 x 1.25
24 GW-9727 Pipe Plug 3/8 NPT
25 642-0002 Inner Tine Assembly RH
26 642-0004 Outer Tine Assembly RH
27 618-04276A Case Assembly
28 721-04157
Gasket
29 726-0299 Push Cap
30 734-0973 Wheel 5 x 1.38
31 749-04265 Depth Stake Tube
32 711-04520 Axle Shaft
33 710-1007 TT Screw 3/8-16 x 1.50
34 786-04296 Wheel Bracket
35 749-04266 Rear Wheel Tube
36 714-3020 Internal Cotter Pin
37 712-04063 Flange Lock Nut: 5/16-18
38 710-0487 Carriage Bolt
39 731-05385 Clutch Cable Fitting
40 746-04247 Clutch Cable
41 710-0599 TT Screw 1/4-20 x .50
42 786-04307 Cable Mount Bracket
43 747-04508 Clutch Bail
44 736-0300 Flat Washer .406 x .875 x .059
Tiller features/compo-
nents vary by model.
Some parts listed may
not be available on your
unit.
