Fully Automatic Type
Climate control information is displayed on the information display.
Temperature setting display (driver)
Ambient temperature /Temperature
setting display (front passenger)
Mode selector display
Airflow display
A/C
DUAL
AUTO
Air intake display
Information display
Front passenger temperature control dial
Windshield defroster switch
Fan control dial
Driver temperature control dial
Air intake selector
OFF switch
AUTO switch
Mode selector
switch
A/C switch
DUAL switch
OUTSIDE (Ambient
temperature) switch
6-6
Interior Comfort
Climate Control System
