qOperating the Moonroof
Tilt Operation
The rear of the moonroof can be tilted
open to provide more ventilation.
To fully tilt automatically, momentarily
push the tilt switch.
To fully close automatically, momentarily
pull the tilt switch or push the front of the
slide switch.
To stop tilting partway, push any part of
the tilt or slide switch.
Tilt up
Close
Tilt down
(Tilt down)
Slide Operation
To fully open automatically, momentarily
push the rear of the slide switch.
To fully close automatically, momentarily
push the front of the slide switch or pull
the tilt switch.
To stop sliding partway, push any part of
the tilt or slide switch.
Open
Close
Tilt down
(Close)
Power moonroof initialization
procedure
If the battery had been disconnected
during vehicle maintenance or for other
reasons, the moonroof may not fully open
or close. The moonroof's jam-safe
function does not function while the
moonroof is initializing. Carry out the
following procedure to resume operation:
1. Turn the ignition switch to the ON
position.
2. Push the tilt switch, to partially tilt
open the rear of the moonroof.
NOTE
If the re-initialization procedure is performed
while the moonroof is in the slide position
(partially open) it closes before the rear tilts
opens.
3. Repeat the procedure in Step 2. The
rear of the moonroof tilts open to the
fully open position, then closes a little.
