qWindshield Wipers
Type A (With INT position)
Turn the wipers on by pulling the lever
down.
INT
― Intermittent
LO
― Low speed
HI
― High speed
For a single wiping cycle, push the lever
up to MIST.
MIST
― Mist
Variable-speed intermittent wipers
Set the lever to INT and choose the
interval timing by rotating the ring.
INT ring
Type B (With AUTO position)
Turn the wipers on by pulling the lever
down.
AUTO
― Auto control
LO
― Low speed
HI
― High speed
For a single wiping cycle, push the lever
up to MIST.
MIST
― Mist
AUTO (Auto-wiper control)
When the wiper lever is in the AUTO
position, the rain sensor senses the
amount of rainfall on the windshield and
turns the wiper on or off automatically
(off
―intermittent―low speed―high
speed).
Driving Your Mazda
Switches and Controls
5-63
