Plug white wire from fan to white
wire from light kit. Then plug blue
wire from fan to black wire from light
kit.
46
Tighten switch housing screws.
48
Remove light rings and save.
50
Raise decorative cover and twist
clockwise until tight.
49
Install switch housing to light kit.
Install lockwasher and hex nut pro-
vided and tighten securely.
45
Plug connector from fan to connector
from switch housing.
47
Drop decorative cover ring over light
kit.
44
Install glass to fitters and then install
the light rings to hold glass in place.
51
Install 3 x 60 watt (E12) base bulbs.
52
Remove cover by snaping off from
top or bottom. Install 12V battery
into wall remote. Duracell MN21 /
Eveready A23 / GP 23A all 12V.
53
Attach cover of remote by placing
over buttons and snaping into place.
54
Raise decorative cover and twist
clockwise until tight.
43
