8
Rear Panel
11. TELEPHONE/MODEM/ETHERNET SURGE PROTECTION
Surge protection for telephone line, modem line, and 10BaseT line to maintain a completely safe
connection for INTERNET/INTRANET service.
12. EXTERNAL BATTERY PACK CONNECTOR (optional)
Allows for extended runtime.
Caution: Use only factory supplied or authorized connecting cable for external battery
pack!
13. SNMP INTERFACE PORT (optional)
This option will allow the UPS to be connected directly to a network and also allow for remote
monitoring. Through the RS-232 communication port, the SNMP adapter makes your UPS
become "SNMP manageable", and provides real time UPS and power status information for the
network manager.
Note: It's not necessary to use this option.
Caution: Use only factory supplied or authorized SNMP monitoring kit.
14. OUTPUT POWER RECEPTACLES
Connect load(s) here.
15. AC INPUT POWER RECEPTACLE
Plug into properly rated outlet.
