MGE UPS Systems GES-102L - Manual (Page 21)

Always “On” UPS Systems Inc.
21
OUTPUT SHORT YES
ABNORMAL VOLTAGE YES
MODEM OR NETWORK SINGLE LINE (2 wire RJ11) / NETWORK (UTP, RJ45) COMPATIBLE JACKS
I/O NOISE PROTECTION COMMON & NORMAL MODE NOISE SUPPRESSION
PROTECTION
I/O SPIKE & TRANSIENT
PROTECTION
YES
COMMUNICATION RS 232 / DRY CONTACT (OPTIONAL SNMP OR AS400)
LED DISPLAY NORMAL / BACKUP / LOW BATTERY / FAULT / CHECK BATTERY / BUCK / BOOST INTERFACE
AUDIBLE ALARMS ON BATTERY, LOW BATTERY, OVERLOAD, FAULT
OPERATING TEMPERATURE 0 - 40°C (32 - 104°F)
HUMIDITY 0 - 95% (NON-CONDENSING) ENVIRONMENT
AUDIBLE NOISE < 40 dBA AT 1 METER FROM UNIT
SAFETY cUL, UL1778, CSA C22.2
EMI / RFI FCC CLASS B SAFETY APPROVAL
SURGE / TRANSIENT IEEE C62.41 CAT.A
UPS WxDxH mm (in.) 140x436x210 (5.5x17.2x8.3) 170x450x226 (6.7x17.7x8.9)
EXTERNAL BATTERY BANK (if
applicable)
INTERNAL BATTERIES
170x450x226
(6.7x17.7x8.9)
PHYSICAL DATA
WEIGHT in kg (lbs) 14.5 (32) 15 (33) 25 (55.1) 30 (66.1)
46 (101.4)
(including battery bank)
MODEL NO. GES-801LR GES-102LR GES-152LR GES-202LR GES-302LR
UPC Order Code 825433 22105 825433 22201 825433 22301 825433 22401 825433 22501
WxDxH mm (in.) 483x381x89 (19x15x3.5) [2U]
483x381x133
(19x15x5.25) [3U]
483x381x178
(19x15x7) [4U]
RACK-MOUNT MODELS
WEIGHT in kg (lbs) 18 (35.3) 20 (44) 26.1 (57.5) 28.4 (62.6) 46.4 (102.3)
