Flat tire – Mazda 2008 MX-5 Miata User Manual
Page 260
Black plate (260,1)
qJack
To remove the jack
1. Turn the knob and remove the cover.
2. Turn the wing bolt and jack screw
counterclockwise.
Wing bolt
Jack screw
To secure the jack
1. Insert the wing bolt into the jack with
the jack screw pointing back and turn
the wing bolt clockwise to temporarily
tighten it.
2. Turn the jack screw in the direction
shown in the figure.
Wing bolt
Jack screw
3. Turn the wing bolt completely to
secure the jack.
NOTE
If the jack is not completely secured, it could
rattle while driving. Make sure the jack screw
is sufficiently tightened.
7-6
In Case of an Emergency
Flat Tire
MX-5_8X49-EA-07F_Edition2 Page260
Monday, June 25 2007 11:19 AM
Form No.8X49-EA-07F
