43
TIMING CHARTS
Figure 15 — Timer Chart and Diagram,
401-HT PLUS, 401- HTN PLUS
TIMING CHART 401-HTM2
TIMER ASSEMBLY 401-HTM2
00042M2
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
TIME IN SECS
CAM
1
2
2
3
4
5
6
7
8
WASH PUMP
WASH PUMP
WASH PUMP
REVERSING CAM
DRAIN VALVE
FILL VALVE
RINSE
DETERGENT
AUTO-FILL
HOMING
CAM
PUMP
DRAIN
PUMP
150
FORWARD=WASH
REVERSE=DRAIN
DRAIN PUMP
OPTIONAL
SYNCHRON
8
7
6
5
4
3
2
1
TIMER MOTOR
LOCKING SCREW
TIMER
SWITCH
DETAIL
N
C
N
O
COM.
9
RINSE
SENTRY
If booster thermostat is calling for heat,
cam 9 will pause wash cycle until it reaches
82 C/180 F.
9
OPTIONAL
