Moyer Diebel 401-HTM2 PLUS - Manual (Page 31)

25
REPLACEMENT PARTS
WASH SYSTEM ASSEMBLY
Fig. 5 Part Description Qty
Item No. No.
1 0508549 Hose, Upper Wash ...................................................................... 1
2 0502563 Clamp, Hose 1" .......................................................................... 2
3 0708650 Spindle, Upper Wash Arm.......................................................... 1
4 0503588 O-ring, 1-1/8" x 1-3/8" ............................................................... 1
5 0501412 Screw 10-32 x 3/8 Truss Head ................................................... 3
6 0508541 Bushing, Upper Wash Arm ........................................................ 1
7 0710593 Wash Arm, Upper....................................................................... 1
8 0505042 Pivot, Upper Wash Arm ............................................................. 1
9 0308783 Retainer, Upper Pivot ................................................................. 1
10 0501563 Screw, #8 x 3/8 Truss Head ........................................................ 2
11 0501684 Nut, Spray Arm Lock ................................................................. 1
12 0705049 Wash Arm, Lower ...................................................................... 1
13 0508540 Bushing, Lower Wash Arm ........................................................ 1
