27
REPLACEMENT PARTS
BOOSTER ASSEMBLY AND WATER INLET PIPING
(HT PLUS ONLY)
Fig. 6 Part Description Qty.
Item No. No.
1 0503679 Clamp, hose ................................................................................ 2
2 0509214 Hose, 1/2" I.D............................................................................. 3 ft.
3 0502653 Elbow, 3/8 MPT X1/2 Hose x 90°.............................................. 1
4 0508840 Bushing, reducing 3/4 NPT x 3/8 NPT Brass ............................ 2
5 0501419 Bolt., 1/4-20 x 1/2" Hex Head.................................................... 2
6 0501501 Washer, Lock 1/4" Split.............................................................. 5
7 108954 Nut, Grip 6-32 w/Nylon Insert ................................................... 2
8 110562 Thermostat, high limit ................................................................ 1
9 0509042 Tank, booster (tank only)............................................................ 1
10 107417 Hose 1/2" I.D. (28") ................................................................... A/R
11 0508817 Plug, pipe 1/8" ............................................................................ 1
12 109985 O ring, gasket ............................................................................. 1
13 111235 Heater element, 6KW (40° rise) 208/230V 1PH........................ 1
14 111233 Heater element, 9KW (70° rise) 208/230V 1PH........................ 1
15 0501539 Nut, plain 1/4-20 ........................................................................ 1
16 107908 Cover, heater element ................................................................. 1
--- 110997 Wire, Jumper Heater Element (Not Shown)............................... 1
--- 0307356 Insulation, Heater Terminal (Not Shown) .................................. 1
--- 0508937 Label, Cover Warning (Not Shown)........................................... 1
