Practical hints
Opening/closing in an emergency
Opening/closing in an emergency
Sliding/pop-up roof*
You can open or close the sliding/pop-up
roof manually should an electrical malfunc-
tion occur.
The sliding/pop-up roof drive is located
behind the lens 1 of the interior overhead
light.
̈ Pry of lens 1 using a flat blade screw-
driver.
̈ Slide both locking tabs 2 in direction of
arrow.
̈ Lower rear of cover and remove.
̈ Remove cover.
̈ Obtain crank 3.
̈ Insert crank 3 through hole.
̈ Turn crank 3 clockwise to:
ț slide roof closed
ț raise roof at the rear
̈ Turn crank 3 counterclockwise to:
ț slide roof open
ț lower roof at the rear
The sliding/pop-up roof must be resyn-
chronized after being operated manually
(
୴ page 192).
i
Do not disconnect electrical connec-
tors.
