MTX80/90 RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (1/14/11) — PAGE 51
CARBURETOR ASSY.
MTX80: S/N T-4419 AND BELOW
MTX90: S/N T-1341 AND BELOW
NO.
PART NO.
PART NAME
QTY.
REMARKS
210
2526257100
CARBURETOR ASSY ...................................... 1 ............... INCLUDES ITEMS W/ #
900#
5016004010
SCREEN INLET
1
901#
2526260508
COVER, METALING DIAPHRAGM
1
902#
2526260408
COVER PUMP
1
903#
2526261208
THROTTLE SHAFT
1
904#
1616233508
VALVE THROTTLE
1
905#
2846260308
SHAFT ASSY CHOKE
1
906#
5106045040
CLIP
1
907#
2846260408
VALVE, CHOKE
1
908#
1616255208
VALVE, INLET NEEDLE
1
909#
1476258408
BALL
1
910#
1616238008
GASKET PLUG
1
911#
1616238108
GASKET, METALING DIAPHRAGM
1
912#
2526261008
DIAPHRAGM PUMP
1
914#
1616238308
DIAPHRAGM ASSY, METALING
1
915#
1066257508
SCREW
1
916#
1066257608
SCREW ASSY
5
917#
1476257308
SCREW
2
918#
2846260008
SCREW
1
919#
1616245408
SPRING, IDLE ADJUST
1
920#
1616245108
SPRING, METALING LEVER
1
921#
1476258308
SPRING, CHOKE
1
925#
1616236808
PIN, METALING LEVER
1
926#
1616236908
LEVER, METALING
1
927#
1476257508
PLUG
1
929#
1616238508
SCREW, IDLE ADJUST
1
943#
2526261108
SPRING PUMP
1
945#
1616255108
STOPPER, THROTTLE
1
946#
2526260308
LEVER, THROTTLE
1
947#
1616255308
SCREW VALVE
2
948#
2526260208
SPACER, THROTTLE LEVER
1
949#
2526260108
WASHER
1
ROBIN EH122D46530 — CARBURETOR ASSY.
