MTX80/90 RAMMER — OPERATION AND PARTS MANUAL — REV. #9 (1/14/11) — PAGE 43
— E— CRANKSHAFT AND PISTON
CYLINDER HEAD ASSY.
NO. PART NO. PART NAME QTY. REMARKS
20# 2371420203 VALVE GUIDE O/S 2
26 2771601001 STEM SEAL 1
60# 0105080480 STUD 2
70# 0105060131 STUD 1
71# 0013906600 STUD 1
72 2533360103 VALVE SPRING 2
73 2693370103 SPRING RETAINER 2
80 2683340103 INTAKE VALVE 1
90 2683350103 EXHAUST VALVE 1
95 13210KA031 COLLET VALVE 4
210 2683530103 PUSH ROD 2
220 2693600103 ROCKER ARM 2
230 2693580103 BOLT, PIVOT 2
240 0170060090 NUT 2
260 2693650103 GUIDE PLATE 1
610 2681310121 CYLINDER HEAD CP ........................................1................INCLUDES ITEMS W/ #
620 2531500133 GASKET, HEAD 1
630 0110080100 FLANGE BOLT 4
680 2521550203 ROCKER COVER 1
690 2691600403 GASKET, ROCKER, COVER 2
710 0110060170 FLANGE BOLT 4
720 2521560120 SPACER ASSY, BREATHER ..............................1................INCLUDES ITEMS W/ $
721$ 2521560113 SPACER, BREATHER 1
722$ 2521600103 LEAF VALVE 1
723$ 2521610103 RETAINER PLATE 1
724$ 2521440123 PLATE 1
725$ 0110060150 FLANGE BOLT 2
726$ 0043506120 SCREW AND WASHER 1
850 2681800503 RUBBER PIPE 1
900 0566000250 CLAMP 1
901 0110060020 FLANGE BOLT 1
910 0561120040 HOSE CLAMP 1
ROBIN EH122D46530 — CYLINDER HEAD ASSY.
