MTD E665E - Manual (Page 26)

26
ENGINE AND “V” BELTS
Ref.
No. Part No.
Description
Ref.
No. Part No.
Description
1 05896A Bracket 17 736-0331 Washer—Bell
2 629-0071 Cord, Extension 18 736-0505 Washer—Flat
3 710-0117 Screw 19 748-0234 Shoulder Spacer
4 710-0157 Screw 20 748-0360 Pulley, Adapter
5 710-0230 Screw 21 754-0346 V-Belt
6 710-0342 Screw 22 754-0430 V-Belt Matched
7 710-0696 Screw 23 756-0313 Idler, Flat
8 710-0888 Screw 24 756-0569 Pulley, Half
9 710-0896 Screw 25 756-0967 Pulley—Auger
10 712-0181 Nut, Hex 26 756-0986 Pulley Half
11 731-1324 Belt Cover 27 756-0987 Pulley Half
12 732-0710 Spring 28 390-985 Starter (645,665)
13 736-0119 Washer—Flat 390-987 Starter
14 736-0242 Washer—Bell 29 — Engine
15 736-0247 Washer—Flat 30 756-0620 Pulley, Half (645,665)
16 736-0329 Washer—Lock 31 756-0621 Pulley, Half (645,665)
