11 Replacement Parts List
CF-W5LWEZZBM
REF. NO and
AREA
PART NO.
DESCRIPTION
Q'TY
E1
CR-2032/K5A
COIN BATTERY
1
E2
DFJK12U112BB
PAD FFC
1
E3
DFJK20T108BB
SW PCB FFC
1
E4
DFJK9000ZA
DRIVE FFC
1
E5
DFJS957ZA
LCD CABLE
1
E6
DFJS979ZA
LAN CABLE
1
E7
DFJS959ZC
MODEM CABLE
1
E8
DFJS960ZA
MAIN SUB CABLE
1
E9
DFJS1020YA
ＤＣ－ＩＮ CABLE
1
E10
DFJS962ZA
SP CABLE
1
E11
DL3U11534ABB
PCB, MAIN
RTL
1
E12
DL3U21534ABB
PCB, USB
RTL
1
E13
DL3U31534ABB
PCB, SW
RTL
1
E14
N1ZYYY000002
ANTENNA PCB-L ASS'Y
1
E16
N1ZYYY000001
ANTENNA PCB-R ASS'Y
1
E18
N5HZC0000019
WIRELESS LAN MODULE
1
E19
UJDA769PD1-A
CD-R/RW&DVD-ROM DRIVE
1
E20
DL3UP1443AAA
PCB, HDD FPC UNIT
1
E21
N3CAYYY00006
HDD （60GB)
1
E22
K1YYZZ000060
CONNECTOR
1
E23
L0AA01A00018
SPEAKER
1
E24
L5EDDYY00001
LCD
1
E25
L9AAA5DB0010
SOLENOID
1
E26
N0GB1J000012
INVERTOR
1
E27
N2AZZJ000038
KEYBOARD US
1
E28
N2EAYYY00008
TOUCH PAD
1
E29
N5HAZ0000014
ＭＤＣ ＭＯＤＥＭ
1
E1001
DL3UP1567LAA
PCB, WWAN
RTL
1
E1002
DL3UP1577LAA
PCB, WLAN ANTENNA UNIT(SUB)
RTL
1
E1003
DL3UP1578LAA
PCB, WLAN ANTENNA UNIT(MAIN)
RTL
1
E1004
DFJS1048ZA
WM CABLE
1
A1
CFAA1623AM9
AC ADAPTOR
1
A2
K2CG3DR00003
AC CORD
1
A3
NCR-B/602A
LITHIUM ION BATTERY PACK
1
A4
DFQX5617ZA
MANUAL
1
A5
DFJS1070ZA
MODEM CABLE
1
A6
DFHR3E85ZA
EDGE PROTECTION SHEET A
1
A7
DFHG1546ZB-0
LCD RUBBER
2
P5
DFPK1194YA
PACKING CASE(OVERSEAS)
1
P6
DFPN0846ZA
CUSHION B
2
P7
DFPN0847ZA
CUSHION T
2
K1
DFBC0314ZB-0
PAD BUTTON
1
K2
DFBD0180ZB-0
POWER SWITCH KNOB
1
Packing Material
Note : Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
Main Block Unit
Mechanical Parts
Accessories
