AC CONNECTION

Insert the small end of the AC adapter into the

jack on the side of the unit. Insert the other end

(with the 2 blades) into a conveniently located

AC outlet having 120V AC, 60Hz. DO NOT insert

into the DC IN CHARGE jack.

AC ADAPTER SPECIFICATIONS: DV9V Z

NOTES:

• To disconnect the AC adapter, remove it

from the DC IN jack on the side of the unit as

well as from the AC outlet.

• Use the enclosed AC adapter for this

product only.

BATTERY PACK INSERTION/REMOVAL

Follow the diagram below to insert or remove the battery pack.

7

POWER SOURCES

TO REMOVE: Slide the Battery Release

switch, then slide in the direction of the arrow

A, then arrow B.

Battery Release Switch

B

A

B

A

1

TO INSERT: Align tabs from the battery into

the holes in the unit, then slide the battery in

the direction of the arrow A, then up in the

direction of arrow B.

Battery Release Switch

B

A

B

A

2

To DC 9V IN Jack
