SPECIFICATIONS

SYSTEM TYPE:

Self-Powered Multimedia Satellite/Subwoofer Loudspeaker System

SYSTEM COMPONENTS:

6½" (165mm) Subwoofer (contains Integrated Power Amplifier)

2½" (65mm) Wideband Satellites (Five)

Control Module

Connecting Cables

OVERALL ACOUSTIC

FREQUENCY RESPONSE:

20 Hz to 20 kHz (+/- 3dB)

MAXIMUM SPL:

100 dB (@ <10% THD/1 kHz)

AMPLIFIER TYPE/

Class A/B Hybrid-Monolithic Design, Proprietary CM-7 Interface, UL 94V-0 Spec Printed Circuit

DESIGN FEATURES:

Boards, Redundant Protection Circuits (Thermal, Short-Circuit, Under/Over Voltage), Gold-Plated Inputs

Outputs, and Mute/Power Circuits

AMPLIFIER POWER:

100 Watts RMS (l x 50 Watt, 5 x 10 Watt) 50 Hz to 20 kHz, all channels driven, 4

@ <0.1% THD

INPUT IMPEDANCE:

> 50k Ohms @ 1 kHz, < 200pf @ 20 kHz

INPUT SENSITIVITY:

INPUT >200mV RMS (minimum required input level to achieve maximum output @ 1 kHz)

DYNAMIC HEADROOM:

>2 dB

INPUTS:

Gold-Plated RCA jack

OUTPUTS:

5 Channel Terminal; Left and Right Satellite Speaker via Push Terminal.

SUBWOOFER:

165mm Poly Laminated Paper Cone with 25mm OFC Voice Coil on TSV Composite Former,

Shielded Magnet Structure

SUBWOOFER ENCLOSURE:

Rigidly-braced MDF (Wood), Computer-Optimized Front-Firing Vented Design

(13.50"H x 8.70"W x 13.40"D) with Turbulence-Free Port and Non-Removable Fabric Grille

SATELLITE SPEAKERS:

65mm Computer-Optimized Wideband Paper Cone Drivers,

Speaker Magnet Structures (magnetic shielding)

SATELLITE ENCLOSURES:

Two-Piece Molded, Dual-Slope Ellipsoidal Acoustic Suspension Design,

(4.00"H x 3.30" W x 4.10"D)

Embedded ¼"-20 Threaded Inserts (for optional mounting brackets) and decorative cloth grilles

CROSSOVER FREQUENCY:

180 Hz

CONTROL MODULE (Preamp):

Patent-Pending S4Bus™ Interface to Integrated Power Amplifier for control of Major System

(1.7"H x 5.8"W x 3.1"D)

Functions—Volume, Balance, Bass, Fade, Treble, Power, Mute

Note

Design and specifications are subject to change without notice.
