8
5.3 Connecting External Sensors
Plug sensor into
Input socket
Tighten screw
securely into flat
on shaft.
Remote Optical
Sensor (ROS-P)
Install with
pin in shaft
fully seated
in slot.
Tighten
screw.
2. 10 cm Wheel 3. 12 inch Wheel OR
Remote Contact
Assembly (RCA)
(shown with optional 12 inch wheel)
€ € € € €
In
S S S S S
Infrared Sensor
(IRS-P)
Magnetic Sensor
with Amplifier
(MT-190P)
15
1. Turn Power
ON
2. Enter Setup
Mode
3. Enter
selection of
Mode
4. Select
TOTAL
Mode
5. Save and
advance
OR Repeat until
TOTAL displayed.
Last Mode selected
is displayed
1a. To toggle Lock On/
Off
Different messages displayed for
Internal or External operation.
Locked On
Internal or External ROS: External RCA:
EXTRN, then scrolling
message, then last
Units selected
Last Units
selected
Press and Hold
8.0 TOTALizer Mode
8.1 TOTALizer Setup
