Getting Started
25
Getting Started with your
Wireless MultiModem
Mechanical Mounting
To mount the Wireless MultiModem, do the
following:
1. Obtain mounting screws (two are needed) that
are appropriate for the surface on which you
will mount the MultiModem. The mounting
screw on the connector end of the unit must
have a screw-head no thicker than 2 mm. The
allowable thickness is limited because the
screw must fit beneath the RS232 cable. The
allowable thickness of the other screw-head is
not limited in this way.
= 2 mm
Screw Head
Clearance
Side View
