Multi-Tech Systems MTCBA-G-F2 - Manual (Page 19)

Specifications
19
Specifications
General Specifications
Power Requirements 5 V to 32VDC; 400mA Average @5V,
2A Peak @ 5V
Mechanical
Dimensions & Weight
4.3" w x 2.4" h x 0.94" d; 4.1 oz.
(11 cm x 6.1 cm x 2.4 cm; 115 g)
Connectors &
Fasteners Antenna Connection type : SMA jack
Serial Connector : 15-pin RS232 SUB
D female (DE15S)
Pins : RS232 link, audio link, BOOT,
RESET
Power Connector : 2.5mm miniature
power jack
SIM receptacle : (standard)
Operating
Temperatures -30 to +60°C
Certifications CE Mark
EMC: FCC Part 2, 15, 22, 24, EN
55022 &
EN 55024
Safety: UL 60950, EN 60950
