Installation page 2 — 3
Installation and User Manual
Figure 2-1: Wiring Diagram for 125VA-1000VA 120VAC Input.
Figure 2-2: Wiring Diagram for 1800VA-2400VA 120VAC Input.
T1
FILTER BOARD
#202901
IL
IN
L
N
LOAD
F1
SHIELD
WIRING DIAGRAM
125VA - 1000VA 120VAC INPUT
120VAC OUTPUT 60Hz
GROUND STUD
(BOTTOM OF ENCLOSURE)
RATING F1
125VA
250VA
500VA
750VA
1000VA
250V
1.5A
250V
3A
250V
6A
250V
12A
250V
8A
1 5
2 6
3 7
4 8
CORE
5-15P
5-20R2
T1
FILTER BOARD
#202901
IL
IN
L
N
LOAD
F1
SHIELD
WIRING DIAGRAM
1800VA - 2400VA 120VAC INPUT
120VAC OUTPUT 60Hz
GROUND STUD
(BOTTOM OF ENCLOSURE)
RATING F1
1800VA
2400VA
500V
20A
500V
25A
1 5
2 6
3 7
4 8
CORE
5-15P
5-20R2
INPUT
PLUG
L5-20P
L5-30P
5-20R2
X W
G
