Figure 1-4: 1.8kVA Isolation Transformer Enclosure.

Figure 1-5: 2.4 kVA Isolation Transformer Enclosure.

Introduction

Topaz 100 Ultra-Isolator Transformer

page 1 — 6

17.00"

(431.8m)

11.096"

(281.8m)

10.486"

(266.34m)

120VAC INPUT
120VAC 60HZ OUTPUT

1.8kVA ISOLATION TRANSFORMER ENCLOSURE

L5-20 INPUT
LINE CORD
8' (203.20m)

SPECIFICATION TAG

INPUT FUSE

5-20R2 OUTPUT

RECEPTACLES

MGE LABEL

17.00"

(431.8m)

11.096"

(281.8m)

120VAC INPUT
120VAC 60HZ OUTPUT

2.4kVA ISOLATION TRANSFORMER ENCLOSURE

L5-30 INPUT
LINE CORD
8' (203.20m)

SPECIFICATION TAG

INPUT FUSE

5-20R2 OUTPUT

RECEPTACLES

MGE LABEL

10.486"

(266.34m)
