Mace DVR0404RW - Manual (Page 20)

20
2. Keys functions
Order Key name Logo Function
Power switch - Power off by pressing the key 4 seconds.
1
Power switch and
indication light
POWER
Indication light
2 Camera Selection
Numbers
1, 2, 3 etc.
Manual Password # input, window shift or number input; 10
is used for numeric input 0.
3 Recording light
LED (Red) on
numbers
If the LED light is RED, it means the recording is on
4 Plastic Cover Black plastic Dust-proof Cover
5 CD-RW CD-RW Used to Back-up records
6 Address ADD
Input remote control address for the operation of DVR.
7 & 13 Left & Right Arrows
L & R On screen Cursor Control; shifting level 1 and level 2
menu; Left and Right Camera Pan control.
11 & 12 Up & Down Arrows
Up and Down Onscreen Cursor Control; change setup;
change number; Camera Tilt control.
8 IR Remote receiver Used to receive the remote signal.
Cancels cursor selection.
9 & 24
Cancel ESC
During playback, restore to real-time monitor.
Enter Cursor Selection.
10 Enter ENTER
Enter main menu.
14
Information INFO
Press to show the system information.
15
Single window display Shift the window to single window
In the Full Screen Mode:
Press the key to display the menu of the Camera PTZ.
When setting Motion Detection fields, Fn1 Enables Cursor
field selection.
16 Function assistant 1
Fn1
During playback, display the playback status bar
17 Function assistant 2
Fn2
During playback work with number key to realize PIP for the
playback and real-time monitor.
18 Multi-Screen Display Select to change from Full screen to multi-window display.
